Dometic | 12 Cu. Ft. Elite Series; Dual Compartment - 4 Door Refrigerator With Freezer; Permanent Bolt-In | RM1350SLM | 12 Cu. Ft. | 2-Way | Door Panels Sold Separately | Black

Dometic RM1350SLM Elite Series 4-Door RV Refrigerator – 12 Cu. Ft., 2-Way AC/LP Gas, Manual Lock, Black, Door Panels Sold Separately

Bring premium residential-style refrigeration to your RV with the Dometic RM1350SLM Elite Series refrigerator. Designed for permanent bolt-in installation, the RM1350SLM combines a spacious four-door, dual-compartment configuration with dependable absorption refrigeration and flexible 2-way operation using 120V AC or LP gas.

The Elite Series RM1350 is designed for RV owners who want generous food-storage capacity, convenient organization, and the flexibility to operate whether connected to shore power or traveling without an electrical hookup. Its divider-less freezer provides wall-to-wall usable freezer space, while three crisper drawers, adjustable shelving, sliding freezer bins, door storage, and interior lighting make it easy to organize fresh and frozen foods.

This RM1350SLM configuration features a manual door-locking system and does not include an ice maker. Decorative door panels are also sold separately, allowing the refrigerator to be integrated into the interior design of the RV.

• Ships for $99.00 Flat Rate Freight
• Does not come include door panels, panels are sold separately

Premium 4-Door, Dual-Compartment Design

The RM1350SLM features a 2+2 four-door configuration with separate upper freezer doors and lower fresh-food compartment doors. This layout provides convenient access to both refrigerated and frozen foods while minimizing the amount of cold air lost when accessing individual sections.

The freezer uses Dometic's divider-less design, providing a continuous, wall-to-wall cooling area without a center divider. This allows larger or irregularly shaped frozen items to be accommodated more easily.

The published storage volume is approximately 12.5 cubic feet under ANSI/AHAM HRF-1-2007 measurement standards, with approximately 9.03 cubic feet dedicated to the refrigerator compartment and 3.47 cubic feet dedicated to the freezer. The product is commonly marketed as a 12 or 13 cubic-foot-class refrigerator depending on the specification source and rounding convention.

2-Way AC/LP Gas Operation

The RM1350SLM is an RV absorption refrigerator designed for 2-way operation. It can operate from AC electrical power when shore power is available or from LP gas when electrical hookups are unavailable.

Electrical specifications:

• 120V AC input

• 12V DC control power

• 3.5A rated AC input current

• 2.5A rated DC input current

• 610W rated AC input power

• 60Hz operating frequency

This dual-power capability makes the RM1350SLM particularly well suited to RV applications where reliable refrigeration is required both at a campground and while traveling or boon-docking.

Electronic Temperature Control

The RM1350SLM uses electronic controls for temperature management. The operating documentation identifies a five-position temperature setting system, with the lower setting representing warmer operation and the higher setting representing colder operation. The refrigerator also incorporates an LED display and electronic controls for convenient operation.

Manual Door-Locking System

This particular RM1350SLM configuration uses Dometic's manual door-locking system. The refrigerator doors automatically lock when closed, while the user can open the doors normally when access is required.

Storage and Organization

The RM1350SLM is designed to provide flexible storage for extended RV travel and includes:

• Three crisper drawers for fresh produce

• Adjustable refrigerator shelving

• Door compartments and shelving

• Dual-action shelf guards

• Sliding freezer bins

• Divider-less freezer compartment

• Interior lighting

• Versatile storage/racking system

The combination of separate refrigerator and freezer compartments with the divider-less freezer design provides substantial usable storage while maintaining the premium four-door configuration associated with Dometic's Elite Series.

Door Panels Sold Separately

This RM1350SLM model is designed to accept separately ordered panels, allowing the finished refrigerator to coordinate with the cabinetry and interior design of the RV.

Dometic's published panel specifications identify maximum panel thickness at approximately 5/32 inch. The required panel dimensions vary by door position, so the appropriate panel dimensions should be confirmed before ordering or fabricating replacement/custom panels.

Please note:Decorative door panels are not included with the RM1350SLM refrigerator.

No Ice Maker Included

The RM1350SLM does not include an ice maker.

Permanent Bolt-In Installation

The RM1350SLM is designed for permanent installation within an RV. It is not a portable refrigerator and should be installed by a Dometic Authorized RV technician, according to Dometic's installation requirements, including appropriate ventilation, clearances, electrical connections, LP-gas connections, and securing hardware.

Because absorption refrigerators require proper airflow and installation clearances to operate correctly, the existing RV cabinet opening and installation configuration should be verified before purchasing or replacing an existing refrigerator.

Physical Dimensions and Installation:

Specifications:

• Height: 64-1/4 inches

• Width:33-11/16 inches

• Depth: approximately 27-1/2 to 29-1/2 inches overall

• Net Weight: approximately 231 lbs.

Dometic specifications identify the required recess/cutout dimensions at approximately:

• Recess Height: 63-3/16 inches

• Recess Width: 32-3/4 inches

• Recess Depth: approximately 27-1/16 inches

Because installation dimensions can differ from the overall exterior dimensions and can vary depending on how depth is measured, the RV installation opening should always be compared against the current Dometic installation documentation before installation.

Technical Specifications:

• Brand: Dometic

• Series: Elite

• Model: RM1350SLM

• Product Type: RV Absorption Refrigerator/Freezer

• Configuration: Dual Compartment, 4 Door

• Nominal Capacity: 12 Cu. Ft. Class

• Published Total Storage Volume: Approximately 12.5 Cu. Ft.

• Fresh Food Capacity: Approximately 9.03 Cu. Ft.

• Freezer Capacity: Approximately 3.47 Cu. Ft.

• Refrigeration Type: Absorption

• Power Type: 2-Way AC/LP Gas

• AC Input: 120V AC

• DC Input: 12V DC

• AC Rated Current: 3.5A

• DC Rated Current: 2.5A

• AC Rated Power: 610W

• Frequency: 60Hz

• LP Gas Consumption: Approximately 2,081 BTU/h

• LP Gas Pressure: 11 in. water column

• Refrigerant: R717

• Temperature Control: Electronic/Automatic

• Door Configuration: Four Door

• Door Lock: Manual

• Installation: Permanent Bolt-In

• Freezer: Yes

• Freezer Configuration: Divider-Less

• Ice Maker: No

• Interior Lighting: Yes

• Crisper Drawers: Three

• Color/Frame: Black

• Door Panels: Sold Separately

• Net Weight: Approximately 231 lbs.

• Overall Height: Approximately 64-1/4 in.

• Overall Width: 33-11/16 in.

• Overall Depth: Approximately 27-1/2 to 29-1/2 in., depending on measurement
• reference

• Recess Height: Approximately 63-3/16 in.

• Recess Width: Approximately 32-3/4 in.

• Recess Depth: Approximately 27-1/16 in.

Technical specifications are compiled from Dometic documentation and current manufacturer/distributor specifications. Minor differences in published capacity, dimensions, or terminology may occur between older and newer specification sheets, so installation should be based on the applicable Dometic installation documentation for the specific unit.

Why Choose the Dometic RM1350SLM?

The Dometic RM1350SLM Elite Series is engineered for RV owners who want a large-capacity refrigerator with the convenience and organization of a four-door design without giving up the ability to operate from LP gas. Its divider-less freezer, three crisper drawers, adjustable storage, electronic controls, and permanent built-in design make it a substantial upgrade for compatible RV installations.

The 2-way AC/LP operating system provides flexibility between campground electrical service and LP-powered operation, while the manual door-lock system provides a straightforward solution for securing the refrigerator doors.

With its black frame, panel-ready door design, four-door configuration, generous storage volume, and Elite Series feature set, the RM1350SLM is designed to provide a premium refrigeration solution for larger RVs and motorhomes.

Important Ordering Information

The Dometic RM1350SLM does not include decorative door panels or an ice maker. Door panels must be purchased separately if a finished panel-ready appearance is desired.

Before ordering, verify the refrigerator model, cabinet opening dimensions, available ventilation, power requirements, LP-gas connection, door swing/hinge configuration, and required installation clearances. Replacement installations should not be assumed to be a direct fit based solely on exterior dimensions.

Manufacturer: Dometic
Model: RM1350SLM
Dometic Product / Part Reference: 9108823667 / 958625499
UPC: 713814210311
