Conjunto de bomba de calor Coleman para techo para instalaciones sin conductos con termostato de pared

Filtrar:

Precio
El precio más alto es $139.99 Restablecer
$
$
Tipo de producto
0 seleccionados Restablecer
Marca
0 seleccionados Restablecer

4 productos

What does the Coleman heat pump ceiling assembly for non-ducted installations include?

The non-ducted ceiling assembly is the lower interior component that mates to a Coleman rooftop heat pump unit. It includes the air distribution grille, return air filter housing, and the integrated controls or wiring harness that connects to a wall thermostat rather than an onboard ceiling control. This configuration is used when your RV does not have ductwork running through the roof, so conditioned air discharges directly into the living space from the ceiling assembly itself.

How do I know if my RV needs a non-ducted or ducted ceiling assembly?

Look up at the interior ceiling grille below your rooftop AC. If the grille has adjustable louvers that blow air directly into the room, your coach is non-ducted and this collection is correct. If the grille is flush and air is delivered through vents located in other parts of the ceiling, your coach is ducted and you need a Coleman Power Saver HP ceiling assembly for ducted installations instead. Always confirm your rooftop unit model number before ordering.

Is a wall thermostat required with this ceiling assembly?

Yes. This assembly is built for systems controlled by a Coleman-Mach wall thermostat rather than a ceiling-mounted control board. The thermostat handles mode selection (cool, heat pump, fan) and temperature setpoints, while the ceiling assembly handles air distribution and filtration. If you are replacing an older ceiling-control system, you will also need to install compatible thermostat wiring.

What other Coleman AC parts and accessories do you carry?

Alongside this ceiling assembly, we stock the Coleman RV air conditioner soft start kit to reduce inrush current and prevent breaker trips on 30-amp service, plus comparison options like the Furrion original ceiling assembly for non-ducted installations if you are sourcing parts for a different rooftop brand. Text or call 817-984-1852 if you need help confirming the right assembly for your unit.
